EMCO HYPERTURN 665

  • Year:
  • 2003
  • Bar Feeder:
  • KAMA 4265 mm
  • Max. Turning diameter:
  • 430 mm dia.
  • Max. Turning dia o/slide:
  • 600 mm dia.
  • Turning Length:
  • 644 mm
  • Dist. between spindels:
  • 975 mm
  • Main motor power:
  • 21/29 kw
  • Main Spindle speed Range:
  • 0-5000 rpm
  • Boring trough drawing pipe:
  • 65 mm dia.
  • C Axis - Mainspindle Stroke:
  • 0.001 degree
  • Y axis :
  • 100 mm +/- 50 mm
  • Turret 1 with :
  • 12 / VDI 30 Stations
  • Live stations in Turret 1:
  • 12 - 4000 rpm pcs.
  • Motorpower M spindle:
  • 6.7 Kw
  • Turret 2 with:
  • 12 Stations
  • C Axis – Sub spindle Stroke:
  • 0.001 degree
  • Sub Spindle Speeds:
  • 5000 pr/min
  • Motor Power Subspindle:
  • 17/22 Kw
  • Control system:
  • Siemens 840 D manuf.
  • Controlled in :
  • 7 ( X1-X2-Z1-Z2_C1-C2-Y) axis
  • Steady rest:
  • https://dentool.dk/maskine/emco-hyperturn-665-3817/ mm dia
  • Weight:
  • 7600 kg
  • Length:
  • 3400 mm + convoyer
  • Width:
  • 2550 mm
  • Height:
  • 2300 mm
Price request

Youtube

Disclaimer

Subject to errors in the above data and intermediate sales. Technical details are delivered in the best way and customers are advised to check all sensitive details. Customers are responsible for ensuring that the machines comply with local safety regulations.
