GILDEMEISTER GDM 42 / 2A
- Machine group:
- CNC LATHE
- Year:
- 1989
- Total Power Source:
- 45 kva
- Main Spindle speed Range:
- 40-6300 - 2 step rpm
- Total motor power:
- 42,5 kW
- Max. Turning diameter:
- 185 / 290 mm dia.
- Boring trough drawing pipe:
- 42 mm dia.
- Tool Turret capacity:
- 12 VDI 3425 - 40 mm stations
- Max. Turning dia o/slide:
- 550 mm dia.
- X Axis Stroke:
- 190 mm
- Z Axis Stroke:
- 450 mm
- Main motor power:
- 22/29 kw
- Hydraulic Main centre chuck:
- 160 mm dia.
- Weight:
- 5300 kg
- Length:
- 3300 mm
- Width:
- 2350 mm
- Height:
- 1800 mm
Youtube
Disclaimer
Subject to errors in the above data and intermediate sales. Technical details are delivered in the best way and customers are advised to check all sensitive details. Customers are responsible for ensuring that the machines comply with local safety regulations.
